Light Curing Adhesives
Chemence® is at the forefront of light curing technology for industrial applications. KRYLEX® light cure adhesives are available in a wide variety of formulations ensuring ideal fit to your production needs. The light cure formulations dispense as a liquid, then cure rapidly upon exposure to 365-405nm light. With our KRYLEX® portfolio of light curing adhesives, we have optimized an extensive range of formulations for bonding, sealing, tacking, coating, encapsulation, laminating and potting.
All KRYLEX® light cure adhesives offer critical benefits to end users including:
- Instant (within seconds) cure on demand with exposure to appropriate light source
- 100% solids, solvent free composition for increased health and safety
- Exceptional shelf life and stability
- Single component formulations for no mixing and easy production automation
- Wide range of formulas for any application need
Chemence® manufactures tonnes of UV light curing adhesives and resins on a monthly basis for industrial applications and the flexography industry. Our experienced chemists regularly synthesize proprietary oligomers and raw materials for our formulations to ensure that our products provide cutting edge performance not available from our competitors.
Whether working on assembling needles for drug delivery or waterproofing electronic devices to increase product reliability, the Chemence® portfolio of light cure adhesives include formulas with some or all of the following properties:
- Viscosities from a few centipoise to thixotropic gels for non-sag vertical application
- Excellent adhesion to most plastics, glass, metals, ceramics and more
- High impact, peel and toughness for durable bonds
- High elongation formulas for flexible substrates
- Ultra-clear formulas for clean aesthetics and invisible bond lines
- Excellent temperature, water and chemical resistance
- Dual cure with secondary moisture, thermal or anaerobic cure mechanisms for shadowed areas
- Fluorescing agents for on part detection and quality assurance on production lines
- ISO10993 biocompatibility for use in medical device assembly
We work with customers regularly to customize UV curable adhesives depending on your requirements. Contact one of our technical specialists today to discuss the formulation of UV light curable adhesives for your design and manufacturing needs.
| Featured Product | ||||||
|---|---|---|---|---|---|---|
| Product | Description | Typical Applications | Color | Viscosity， CPS | Hardness | UV/LED |
| KM9904 | ISO 10993-5, Fast curing, Strong adhesion to medical device plastics | Tube set bonding, needle bonding | Translucent | 450 | – | 365 -405nm LED 30 mW/cm2 |
| KU5001T | High adhesion to metals and plastics / Good Depth of cure | Encapsulant | Translucent | 4200 | 75D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5003 | High adhesion to metals and plastics / High Impact strength | Gap filling and sealing | Clear – Amber | 160 | 44D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5003T | Thixotropic version of KU5003 | Structural Bonding, Encapsulation | Clear – Amber | 1000 | 44D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5016 | High Peel strength for flexible substrates/ Excellent adhesion to PA and PET / Tack free | Flexible substrate bonding – High Peel force bonds – wire fixing, flex circuit | Clear | 4500 | 68D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5023 | Higher peel strength than 5016 , tacky, low shrinkage – ‘DispensiblePSA’ (High tack after UV Exposure) | Flexible substrate bonding – High Peel force bonds – wire fixing, flex circuit | Clear | 1500 | 365 -405nm LED 30 mW/cm2 , 2500 mJ | |
| KU5026 | Excellent cure speed – 2 second cure/ Excellent Adhesion to PC, LCP and other difficult to bond plastics / Good Impact Performance | Lens to Barrel, General Purpose plastic to plastic and plastic to metal bonding | Translucent | 9800 | 55D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5027 | Soft/ Very High Elongation – High Impact strength | Lens to Barrel, High Impact Plastic Bonding | Translucent | 12600 | 37D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5029 | Medium softness and elongation (between KU5026 and KU5027) | Lens to Barrel, High Impact Plastic Bonding | Translucent | 10100 | 45D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5039 | High Tg ~115 ◦C. Meets High temperature resistance (>120◦C) and High temperature and heat humidity (85C/85%RH) requirements/ Good Adhesion to metals and plastics/ Good Impact and drop performance | Excellent Temp Humid/ Excellent Adhesion to metals and plastics/ Good Impact and drop performance | Translucent | 6000 | 85A | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5040 | Excellent Temp Humid/ Excellent Adhesion to metals and plastics/ Good Impact and drop performance | Excellent Temp Humid/ Excellent Adhesion to metals and plastics/ Good Impact and drop performance | Translucent | 4800 | 50A | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5045 | Fast cure, low shrinkage, Tack Free/ Good Adhesion to plastic substrates, metals and glass | Battery Pouch Seal/ Sealing | Black | 7000 | 42D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5144 | Low tack/ Excellent Adhesion to PET and Nylon and other plastic substrates | Battery Pouch Seal/ Sealing | Black | 7000 | 54D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5145 | Clear version of KU5144 | Battery Pouch Seal/ Sealing | Clear | 7400 | 51D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5146 | Fast Cure/ Optically Clear/ Good adhesion to plastic, metal and glass/ Good Abrasion and scratch resistance (Pencil hardness -6H)/ High Refractive index (1.56)/ Non yellowing | IR Glass Bonding, Optical bonding, General purpose bonding of dis-similar substrates | Optically Clear | 310 | 83D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5147 | Fast cure version of KU5144, Optimized for 365nm LED cure, low tack/ Excellent Adhesion to PET and Nylon and other plastic substrates | Battery Pouch Seal/ Sealing | Black | 6100 | 58D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5156 | Excellent adhesion to LCP and Nylon, Low shrinkage and high TI | Lens-to-Barrel Bonding | Clear | 11,800 | 72 | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5165 | Low extractable, IBOA Free, Water Resistant | Medical Device Assembly | Clear | 18.000 | 35 | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5225 | Excellent cure speed – 2 second cure/ Excellent Adhesion to PC, LCP and other plastics/ High Impact Performance | Encapsulation of components | Clear | 4000 | 50D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5301 | Exceptional adhesion to PC and other plastics/ Good Flexibility | Adhesive, Sealant | Clear | 250 | 55D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5302 | Exceptional adhesion to PC and other plastics/ Good Flexibility | Sealant or potting | Clear | 5400 | 55D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5303 | High Adhesion of difficult to bond to surface | Potting or encapsulation | Yellow | 22000-28000 | 75D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5304 | Very low Viscosity/ Tack Free/ Good adhesion to glass, PCB’s and metal | Low Viscosity capillary flow UV | Clear | 45 | 83D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
| KU5305 | High adhesion to metals, plastics and glass | Low Viscosity capillary flow UV | Clear | 60 | 55D | 365 -405nm LED 30 mW/cm2 , 2500 mJ |
